ROBOT ARM UR-1000

Contact

Basic parameters
Payload 5 kg (11 lb)
Reach 954 mm (37.6 in)
Degrees of freedom  6
Typical Consumption  350W
Temperature -10-50 degrees C(14~122 degrees F)
Performance
Force/torque sensor  Force, x-y-z
Range  200N
Max affordable force 3000N
Overall accuracy 1% FS.
Distinguishability  0.1N
Physical
IP classification  IP 65
Robot mounting  Any orientation
Footprint  158 mm (6.220 in)
Materials  Aluminium, PC
Robot connection cable length  6m (236 in)
Weight  23 kg (50.7 lb)
Humidity  10~90% RH



Description

The UR-1000 is a versatile 6-axis robotic arm designed for precision tasks across manufacturing and automation lines. With a 1,000 mm reach and 8 kg payload capacity, it’s ideal for welding, assembly, packaging, and pick-and-place operations. The UR-1000 features ±0.02 mm repeatability, a compact footprint, and seamless integration with most PLCs, vision systems, and safety cages. Its modular end-effector mount supports a wide range of tools, while intuitive programming via touchscreen or PC software simplifies deployment. Built for continuous industrial use, the XR-1000 combines durability, performance, and cost-efficiency—making it a dependable solution for mid-scale automation needs.
